200M Meteorological System

  • 1
    Primary measurement technique
  • 2
    High accuracy and reliability
  • 3
    Certificate of Traceability to NIST provided
  • 4
    Sensing scheme discriminates between dew and contamination
  • 5
    Reduces maintenance requirements
  • 6
    No drift, no hysteresis
  • 7
    Fast response
  • 8
    No sensor calibration required
  • 9
    Self-diagnostics and continuous unattended operation. No balancing or other adjustments required
  • 10
    Chilled mirror sensor selection required
The Model 200M is a complete instrument for the measurement of Atmospheric Dewpoint, Ambient Temperature, % Relative Humidity, or other Psychrometric Variables. It employs the very reliable optical chilled mirror sensing technique which provides a primary measurement of dewpoint, and is traceable to NIST. The Model 200M is ideally suited for installations requiring continuous, automatic, and unattended measurement of humidity over a very wide range.

Automatic Balance Control (ABC) cycle corrects the light reducing effects of mirror contaminants and allows for continuous monitoring and virtually maintenance-free operation. This is the first and only chilled mirror technology that truly reduces the need for cleaning by the incorporation of self-diagnostics, which indicates to the user, locally via an LED light source and remotely via logic level TTL signal, when and if maintenance is required.
